Anesthesia Accessories
Large tank Oxygen Pressure Regulator
This medical oxygen regulator is preset to 50 PSI for ideal use with a veterinary anesthesia machine and may be used on large oxygen tanks such as H or K tanks. A male DISS-F connector allows easy connection to any O2 hose equipped with a DISS-F connector.
| Model | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|
| a508 | Pressure Regulator | $105 | Add To Cart |
E -Tank Oxygen Pressure Regulator
This medical oxygen regulator is preset to 50 and equipped with a CGA-870 E- tank yoke for use with small oxygen tanks. A male DISS-F connector allows easy connection to any O2 hose equipped with a DISS-F connector.
| Model | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|
| mr-870-p | Small Tank Oxygen Regulator | $102 | Add To Cart |
Ohmeda & Chemetron Oxygen Quick-Connects
Male Quick-connects are attached to the end of the anesthesia machine hose. Female connectors shut off the flow of oxygen unless connected to a male, and may be used for ceiling drops, etc. Custom lengths of green high-pressure O2 hose may be ordered by the foot and fitted with the connectors of your choice. DISS-F "screw-on" connectors are available to attach opposite end of hose to a cylinder regulator, anesthesia machine, or a ceiling/wall outlet. Quick-connects ordered without a hose will come with DISS-Male adapters unless otherwise specified.
| Model | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|
| 34020 | Ohmeda Male Quick-Connect | $48 | Add To Cart | |
| 34020f | Ohmeda Female Quick-Connect | $48 | Add To Cart | |
| 34010 | Chemetron Male Quick-Connect | $48 | Add To Cart | |
| 34010f | Chemetron Female Quick-Connect | $48 | Add To Cart | |
| 25000 | Oxygen Hose Per/Foot | $2.8 | Add To Cart | |
| 24240 | DISS Female Threaded Connector | $9 | Add To Cart |
Connect2 Medical Gas Wall Outlets
Connect2 outlets are the first gas outlets that accept both Ohmeda and Chemetron Quick-Connect Adapters; features push button release mechanism for Chemetron adapters, and twist mechanism for Ohmeda adapters. All outlets feature fail-safe color coding and safety keyed to ensure appropriate gas. All items below are domestic, ISO item numbers are available.
| Model | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|
| item-64-02-5001 | Connect2 Oxygen Quick-Connect outlet | $79 | Add To Cart | |
| item-64-02-5002 | Connect2 Vacuum outlet | $79 | Add To Cart | |
| item-64-02-5003 | Connect2 Air outlet | $79 | Add To Cart | |
| item-64-02-5004 | Connect2 Nitrous Oxide outlet | $79 | Add To Cart | |
| item-64-02-5006 | Connect2 Gas Evacuation outlet | $79 | Add To Cart | |
| item-64-04-5601 | DISS Oxygen screw-on outlet | $79 | Add To Cart |
Medical Gas Outlets
| Model | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|
| o-qdwal-u-wag | Waste Gas Wall – Ohmeda-F Quick | $65 | Add To Cart | |
| o-diswal-u-wag | Waste Gas Wall – DISS screw-on | $65 | Add To Cart | |
| o-diswal-u-vac | Vacuum Wall – DISS screw-on | $65 | Add To Cart | |
| o-qdwal-u-vac | Vacuum Wall – Ohmeda-F Quick-Connect | $65 | Add To Cart | |
| o-chwal-u-oxy | Oxygen Wall -Chemetron-F Quick -Connect | $65 | Add To Cart | |
| o-qdwal-u-oxy | Oxygen Wall – Ohmeda-F Quick-Connect | $65 | Add To Cart | |
| o-diswal-u-oxy | Oxygen Wall – DISS screw-on | $65 | Add To Cart |
*For Ceiling Outlets: Substitute “CEI” for “WAL” in Item #
Installation Specifications
Ceiling Drop Hose & Hose Retractor
These versatile hose assemblies are manufactured with CGA standard color-coded medical grade conductive hose and attach to standard ceiling outlets with secure DISS screw-on connectors. At the bottom of the hose drops are Female Quick-connects which allow fast access to an anesthesia machines equipped with a male Quick-connect. Hose retractors can be mounted directly on the ceiling outlet or to the ceiling. *Please specify the ceiling height as well as gas type, and connector type when ordering. (O2, Air, Vac, N2O. CO2 and Evac).
| Model | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|
| s-hose-ret | Hose Retractor w/ 48″ Stainless Steel Cable | $55 | Add To Cart | |
| c4oxy060fnnchf | 60″ Oxygen – Chemetron Quick-Connect | $79 | Add To Cart | |
| c4oxy060fnnohf | 60″ Oxygen – Ohmeda Quick-Connect | $69 | Add To Cart |
F/AIR Scavenger System
This economical and practical passive scavenger system incorporates replaceable filter cartridges to absorb waste gases. Activated charcoal filter absorbs 125% of its own weight. Kit includes one cartridge, scavenger hose, Pop-off connection adapters, and cartridge holder bracket.
| Model | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|
| 80120p | Carton of 8 Replacement cartridges | $70 | Add To Cart | |
| 80120 | Replacement cartridge | $8.8 | Add To Cart | |
| 80000 | F/AIR KIT | $28 | Add To Cart |
Veterinary Active Gas Scavenger
| Model | Specifications | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|---|
| 91515179 | 20'(6m) of 32mm tubing, 18'(5.5m) of 19mm tubing & mounting hardware | Wall Mount Scavenger | $1057 | Add To Cart | |
| 91515178 | 20'(6m) of 32mm tubing, 5'(1.5m) of 19mm tubing & mounting hardware | Portable Post Mount Scavenger | $1057 | Add To Cart |
Waste Gas Evacuation Fan
OSHA compliant method for removing anesthesia waste gas to outside air. Ultra-quiet, high quality American made ball bearing motor has five times the life span of a regular bearing motor and uses less electricity. Includes built-in circuit breaker, hour meter, stainless steel enclosure, mounting brackets, and 5 year or 10,000 hour warranty. No balancing outlets are required - Uses model EVC680 outlets and standard scavenger interface valves.
- Capacity: 1-30 anesthesia machines.
- Inlet/outlet: 2" PVC or ABS Pipe
- Electrical: 115V, 50-60Hz (Full load amps 3.0)
- Compliance: UL recognized US & Canada, Certified to UL-507 standards from TUV-SUD America inc. Certified for US & Canada.
| Model | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|
| evc3000 | Waste Gas Evacuation Fan | $1220 | Add To Cart |
Waste Gas and Liquid Evacuation Fan
Waste gas and liquid aspiration in one unit! This waste gas evacuation system utilizes a sealed evacuation unit to remove waste gases to the outside air. This is an OSHA compliant method of removing waste gases from the anesthesia machine using a high quality, ultra quiet, American made motor. Maintenance free design provides years of trouble free service. Compatible with standard medical gas outlets outlets with ¼ NPT Male copper pipe thread. Features built-in circuit breaker, hour meter, stainless steel enclosure, mounting brackets and 5 year or 10,000 hour warranty.
- Capacity: 1-20 Anesthesia Machines; 5 anesthesia machines and 2 liquid aspiration outlets; 10 anesthesia machines and 1 liquid aspiration outlets; 20 anesthesia locations using standard WAGD wall outlets
- Electrical: Voltage: 115, Hz: 50/60 Full Load Amps: 4.0
- Inlet & Outlet: 1/4 NPT Male pipe thread
- Agency Compliance: UL Recognized US and Canada (E47479), Certified to UL-507 standards from TUV-SUD America Inc. Certified for US and Canada
| Model | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|
| evc3100 | Waste Gas Evacuation & Liquid | $1820 | Add To Cart |
Veterinary Anesthesia Waste Gas Interface
A waste gas interface device must be used to reduce negative pressure (vacuum) if you are using central medical suction as a gas scavenger system. By balancing pressures between the anesthesia machine and the active evacuation, this device eliminates the possibility of having a "light" patient due to excess negative pressure. Model A629 with a flowmeter eliminates the need for a separate vacuum regulator when using medical suction. Includes 20 feet of 22 mm clear tubing, 4 feet of 19 mm tubing, and mounting hardware. 5 year warranty.
| Model | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|
| a630 | Waste Gas Interface | $250 | Add To Cart |
Veterinary Waste Gas Interface With Flowmeter
A waste gas interface device must be used to reduce negative pressure (vacuum) if you are using central medical suction as a gas scavenger system. The 7 lpm preset built in flowmeter eliminates the need for a separate vacuum regulator and allows an anesthesia machine to be used with central medical suction systems. Flowmeter barb connects to standard waste gas or vacuum hose. Includes 4 feet of 19 mm tubing, and mounting hardware for all 2" posts. 5 year warran
| Model | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|
| a629 | Waste Gas Interface with Vacuum Flowmeter | $270 | Add To Cart |
Waste Gas Scavenging Outlet
These versatile scavenger outlets can be used in wall or ceiling and accept both 19mm & 22mm diameter scavenger hoses. Includes wall/ceiling rough in box, 19/22 mm tubing nipple and wall cover trim plate. Designed for scavenger systems using 2" PVC pipe reducing to ½" diameter PVC.
| Model | Description | Price | Add To Cart | Add To Quote |
|---|---|---|---|---|
| evc680ps | Evacuation Ceiling Outlet | $58 | Add To Cart | |
| evc680 | Evacuation Wall Outlet | $58 | Add To Cart |
